Article number
|
18600000
|
18601000
|
18602000
|
|
Permissible mains voltage
|
220–240 V
|
120 V
|
100 V
|
|
Permissible mains frequency
|
50/60 Hz
|
50/60 Hz
|
50/60 Hz
|
|
Power consumption (during drilling)
|
115 W
|
115 W
|
115 W
|
|
Power consumption (Stand by mode)
|
1,5 W
|
1,5 W
|
1,5 W
|
|
Laser-Class
|
2
|
2
|
2
|
|
Laser Wavelength
|
630–680 nm
|
630–680 nm
|
630–680 nm
|
|
Output power P0
|
1 mW
|
1 mW
|
1 mW
|
|
Sound pressure level (LpA) (in accord. with DIN EN ISO 11202)
|
70 dB(A)
|
70 dB(A)
|
70 dB(A)
|
|
Dimensions (W x H x D)
|
180 x 368 x 275 mm
7.1 x 14.5 x 10.8 "
|
180 x 368 x 275 mm
7.1 x 14.5 x 10.8 "
|
180 x 368 x 275 mm
7.1 x 14.5 x 10.8 "
|
|
Permissible drill shaft diameter Ø
|
3 mm (+ 0 mm / - 0.006 mm)
|
3 mm (+ 0 mm / - 0.006 mm)
|
3 mm (+ 0 mm / - 0.006 mm)
|
|
Permissible drill length
|
38–40 mm
1.5–1.57 "
|
38–40 mm
1.5–1.57 "
|
38–40 mm
1.5–1.57 "
|
|
Weight
|
~7,6 kg
~16.8 lbs
|
~7,6 kg
~16.8 lbs
|
~7,6 kg
~16.8 lbs
|
