Whip Mix has developed a 3D printed resin that is rigid and durable for dental splints. The additive manufacturing of splints provides a high level of efficiency by removing several lengthy steps and lowering the cost of materials. It also brings a greater degree of digital design flexibility into the process, which improves both the lab’s and the patient’s experience.
This product is compatible with 385nm Asiga Max and Asiga Pro 4K 3D printers and the Whip Mix VeriLUX, the Otoflash, the Uvitron UV IntelliRay 600, the Uvitron SunRay 400 UV, and the CUREbox Plus Curing Units.
VeriSPLINT OS is packaged in 1kg (910ml) bottles.
Features of VeriSPLINT OS:
Though VeriSPLINT OS 3D printing resin is fast to print, it produces an accurate, high-quality, economical splint. Customers can now 3D print on a full build platform with up to four splints in under ONE hour, at just $5.00 – $6.00 per splint.
It is a fully biocompatible material, with 510(k) approval. It has also been validated on Asiga 385nm DLP printers and the Otoflash curing unit.
Biocompatibility:
In accordance with ISO 10993-1 guidance, Whip Mix proudly passed all of the testing required by its categorization. VeriSPLINT OS is a fully biocompatible resin and meets the requirements of ISO 10993-1:2009
Additional VeriSPLINT OS features include:
- Transparency
- Biocompatibility
- Polishability
- Cost effectiveness
- Three year shelf life
Properties based on ISO 20795-2
Ultimate Flexural Strength
≥ 100 MPa
Flexural Modulus
≥ 2500 MPa
Maximum Stress Intensity Factor
1.75
Total Fracture Work
596
Sorption
29
Solubility
< 1
Residual Monomer
< 0.10%
Biocompatibility (ISO 10993-1:2009)
Pass
